Specifications
Semi-Industrial Features
- 6 Needles - 1 position for each needle
- Maximum embroidery speed 1,000 stitches per minute
- Embroiders up to 7-7/8" x 11-3/4" (200mm x 300mm) embroidery field
- Stitch reading capacity:
- 500,000 Stitches per design, or
- 500 Color changes, or
- 100 Combined designs
Technology Features
- TruView™ ASV LCD Color Touch Screen
- Shows 16,770,000 colors
- Measures 8.5" diagonally
- 160 degrees for optimum viewing
- Adjustable screen brightness
- TruView™ WVGA HD Touch Screen Shows:
- Design placement using drag and drop capabilities
- Estimated embroidery time display and stitch count
- Needle advancement (1, 10, or 100, or 500 stitch increments)
- Measurements displayed in inches or millimeters
- Color separation
- Thread color indicator
- On–screen hoop size indicator
- 300 Color names
- Screen saver customization
- Customizable mouse pointer
- Needle Beam for precise alignment
Convenience Features
- Increased CPU processing speed (3 times faster than BMP8)
- Built-in memory (1.7MB)
- Bobbin system: front loading, vertical rotary hook
- Uses pre-wound bobbins (Class "L")
- Push button, automatic needle threader
- 2 LED lights to illuminate work area
- Upper thread breakage sensors
- Manual tension contr
- Automatic thread trimmer (upper and lower)
- Start/Stop button with lock feature
- On-screen speed control while stitchin
- Change screen and thumbnail background color
- Built-in holder with stylus
- Change embroidery position using speed keys
- Needle bar/frame move key extends the hoop for easy access.
- Enhanced appliqué display functions
Software/Connectivity
- Optional External USB 1GB Flash Drive compatible up to 32GB
- 3 USB drives; 2 (Type A) drives, version 2.0 connects with flash drives and CD-ROM drives and version 1.1 connects with mouse, hub, and floppy drives, and 1 (Type B) USB direct connects to a PC
- Reads multiple formats (PES, PEC, DST, PHC)
- Upgradeable through USB connection or removable flash drive
- Linking capabilities connect up to 4 machines using Palette 9 software through a powered hub (Compatible machines include BMP9 with upgrade, BND9-2, BND9, BNT10 and BNT10L)
Customizing Features
- Built-in embroidery designs
- 70 Designs
- 33 Fonts including large floral alphabet, Baby Lock exclusive script, Greek letters, and 3 monogram designs with font frames
- 120 Frame combinations
- Combine embroidery designs on screen
- Character/text array function
- Character spacing
- Pattern rotation (1°, 10°, and 90°)
- Design size change (10% reduction and 20% enlargement) on most designs
- Needle forward and reverse position placement (1, 10, 100, or 500 stitch increments)
- Easy-to-use switch spool key to rotate color spools on screen
- Design duplication (up to 20 times in both directions)
- Automatic appliqué stitching
- Automatic basting
- Mirror imaging
- Increase design thumbnail from 100% to 150% for easy viewing
- Change color selections within designs
- Continuous border capabilities and color sorting on border designs
- Monochrome option for embroidery designs
- Short stitch delete
- Instant needle edge placement (9 starting and 9 ending positions)
- Thread color display in 6 options
- Custom color displays in 3 options:
- Original Palette, Custom Palette 1, Custom Palette 2
- 4 Included embroidery hoops:
- 7-7/8" x 11-3/4" (200mm x 300mm)
- 5-1/8" x 7-1/8" (130mm x 180mm)
- 4" x 4" (100mm x 100mm)
- 1-1/2" x 2-3/8" (40mm x 60mm)
- Hoop sensor advises hoop size for design chosen
- On-screen count and running time system
Support Features
- Built-in operation guide with 4 videos
- Built-in help messages
- Auto save feature - automatically saves last design when power is turned off or a power failure occurs
- • Shipping weight (117 lbs. or 53 kg.)
- Machine weight (81 lbs. or 37 kg.)
Warranty
- 25-year product casting
- 5-year circuit boards
- 5-year electrical
- 2-year parts
- 1-year labor
