Specifications
Technology Features
- Color LCD Touchscreen (4.85" X 2.5")
- Advanced Needle Threading System
- Automatic thread cutter
- Quick-Set, top loading bobbin
- Automatic Thread Tension Control
- Quick-Set bobbin winder
- Automatic sensors
- Thread tension control makes adjustments to feed thread properly
- Upper and lower thread sensors alert when threads are broken
- On-screen hoop sensor recommends size of hoop to use
Embroidery Editing Capabilities
- Combine embroidery designs onscreen
- Font editing
- Size and select letters individually
- Ability to split text
- Multi-color text
- Multiple fonts
- Multi-line text
- Character/text array function
- Character spacing
- Horizontal and vertical options on Japanese fonts
- 1°, 10°, and 90° Pattern rotation
- Design enlargement and reduction (up to 20% down to 10%) • Mirror imaging
- Design color selections
Embroidery Capabilities
-
Embroidery design library built-in
- 181 Built-in embroidery designs including 90 Baby Lock exclusive designs
- 140 Frame combinations
- 13 font styles including one exclusive script
- Embroiders up to 6-1/4" x 10-1/4" (160mm x 260mm) embroidery eld
- 1MB memory storage for embroidery
- Reads embroidery designs with a stitch capacity of up to 200,000 stitches per design
-
Color LCD Touch Screen (240 x 320 dot matrix) shows
- Estimated embroidery time display and stitch count
- Needle position placement (1, 10, or 100 stitch increments)
- Measurements displayed in inches or millimeters (mm)
- Thread color indicator
- On-screen hoop size indicator
- Low bobbin thread indicator
- 300 color names
- Embroidery speed up to 850 spm
- Trims jump stitch threads
- 9-point trial check points
Convenient Sewing Features
-
Convenient One-Touch Buttons for
o Start/Stop
- Needle up/down
- Thread cutter
- Automatic presser foot lift
- Low bobbin thread indicator
- Carrying handle
- 8.3" Workspace to the right of the needle
- 2 LED Enhanced lights that illuminate the needle and work area
Warranty
- 25 years limited
- 10 years parts
- 5 years computer circuit
- 5 years electrical
- 1 year labor
