Specifications
Technology Features
- LCD Color Touchscreen with touch pen
o Shows 260,000 colors
- Measures 7" diagonally
- Clock and Date
- LED Needle Beam for precise placement of needle position
-
Sensor Pen allows you to set preferences on your fabric
- See the needle position location
- Select precise placement for embroidery design
- Enhanced Stadium Lighting™ for brighter true color LED lighting of 10" around the needle
- 2 USB drives: 1 (Type A) drive, 2.0 connects with a mouse, hub, flash drives and CD-ROM drives and 1 (Type B) USB direct connect to a PC
- Access designs stored in folders when using USB type A
- NeverMiss™ Threading System
- Automatic thread cutter
- Quick-Set, top-loading bobbin with sensor
- Quick-Set independent bobbin winding system with variable speed
-
Automatic sensors
- Thread tension control makes tension adjustments for accurate stitches
- Upper and lower thread sensors to alert when threads run out
- On-screen hoop sensor to recommend size of hoop
- Embroidery speed up to 1,050 spm
Embroidery Features
- Built-in embroidery design library
- 263 Embroidery designs built-in
-
166 Baby Lock exclusive designs
- 12 Floral vine alphabet accents and frame patterns
- 13 Bobbin work designs
- 140 Frame combinations
-
19 Font styles including:
- Exclusive script alphabet characters
- Large floral vine alphabet
- Embroiders up to 8" x 12" (200mm x 300mm) embroidery field
- Memory capacity 1MB
- Reads embroidery designs with a stitch capacity of up to 500,000 stitches per design, 125 color changes
-
Color Touch Screen shows
- Design placement using drag and drop capabilities
- Estimated embroidery time display and stitch count
- Needle advancement (1, 10, 100, or 500 stitch increments or entire thread color)
- Measurements displayed in inches or millimeters
- Color separation
- Thread color indicator
- On-screen hoop size indicator
- Low bobbin thread indicator
- 300 color names
- 9-point trial checkpoints
- Starting point key for instant alignment of characters or patterns
- Customize embroidery pattern and thumbnail background colors (66 options)
- Resume feature
- On-screen grid
- Cuts jump stitches (with on/off capability)
- Stitch Count System - .SCS
Embroidery Editing Features
- Combine embroidery designs on screen
- Character/text array function
- Multi-Line text function
- Character spacing
- 1°, 10°, and 90° Pattern rotation
- Design enlargement (up to 20%)
- Design reduction (up to 10%)
- Automatic basting
- Mirror imaging
- Change color selections within designs
- Color sorting on border designs
- Monochrome option for embroidery designs
- Programmable custom thread color selection
Warranty
- 25 yrs. limited
- 10 yrs. parts
- 5 yrs. electrical
- 1 yr. labor
