Specifications
Technology Features
- WXGA IPS TFT LCD Color Touch Screen Technology
- Shows 16,777,216 colors
- Measures 10.1" diagonally (800 x 1280 pixels)
- Displays Clock and Date
- 3x faster processing speed
-
Mpeg-4 movie/video play function
- Video display size 6.2" diagonally
- Exclusive 1GB Memory Storage for video
- IQ Visionary™ Projector
- Projects your embroidery design in a 3" x 5" (7.6 cm x 12.7 cm) area
- Advance and select stitches from projection using the Dual Function Stylus
- Select background color from projection using Dual Function Stylus
- Set width, length and left/right shift
-
Projection of Guide Beam, Grid and Needle Beam for precision
alignment of stitches
- Main and Sub line Options
- 3 Color Options (Red, White, Green)
- Line length and single point options
- Horizontal and vertical position options
- 45, 60 and 90 Degree angles
- Grid adjustable up to from 5mm to 30mm (3/16" x 1-3/16")
- 4 adjustment levels on projection light
- NeedleCam™ Digital Camera for embroidery and sewing positioning with faster scanning.
- Precise Touch Positioning™ using NeedleCam
-
Camera detecting buttonhole foot with stabilization plate
- Creates up to 45mm buttonhole
-
IQ™ Designer with paper holding frame for image scanning
- LCD screen size can be enlarged to 1280 x 800 pixels
- Will automatically create an embroidery pattern from a JPEG image
- Drawing area is 3-3/4" x 5-11/16" (96mm x 145mm)
- 90 Preloaded open, closed and region shapes
- Able to select different line colors and fill colors
- 18 Different stitch patterns: running, bean, satin, no outline, chainstitch, blanket, blindhem, candlewicking and 10 decorative stitch outlines
- 45 Different fill patterns: regular fill, no fill, stipple, and 42 decorative pattern fills
- Duplicate and paste editing preloaded shapes
- Adjust line, fill and stippling width, length and density properties
- Light fill or regular fill for decorative fill patterns
- Undersewing options
- Undo and Redo options
- Outline stamp shape creation for Trapunto techniques
- 2 scanning modes
- Fine - For illustrations
- Standard - For line drawings
- Enhanced Stadium Lighting for 13" area of brighter true color LED lighting on the needle and work area with 5 settings
- 2 (Type A) USB 2.0 drives to connect a mouse, Flash drives, and CD-ROM drives
- SD Card Slot
- Wireless Wi-LAN Function data transfer technology (Requires Palette 11 version software and/or free Intuition Positioning App)
- NeverMiss™ Automatic Advanced Threading System
- Digital Dual-Feed System ensures utmost fabric control when feeding layers or difficult fabric types
- Advanced Pivoting Feature and Automatic Fabric Sensor System
- Automatic sensors
- Thread tension control makes tension adjustments for accurate stitches
- Upper and lower thread sensors on/off
- Upper and lower thread sensors to alert when threads run out
- On-screen hoop sensor to recommend size of hoop
- Embroidery and sewing speed up to 1,050 spm
- Precise tracking system on embroidery carriage
- Resume mode for Embroidery and IQ Designer
- Programmable shutoff capabilities
- Eco power mode
Embroidery Capabilities
- 865 Embroidery designs built-in including
- 355 Baby Lock exclusives
- 35 Sewlebrity designs
- 15 Buttonhole embroidery designs in 5 sizes (75 total)
- 15 Buttonhole embroidery frame designs
- 244 Large decorative stitch designs
- 30 Quilting Border Patterns in 3 categories
- 40 Couching patterns
- 140 Frame combinations
-
32 font styles including
- Extra-large striped alphabet and characters (100 total)
- Extra-large block alphabet and characters (100 total)
- Exclusive script alphabet and characters (70 total)
- Large floral block alphabet (64 total)
- Large vine alphabet (60 total)
- Greek alphabet (24 total)
- Embroiders up to 10 5/8" x 16" (272mm x 408mm) embroidery field
- 10 5/8" x 16" hoop has new locking mechanism and silicone side grips for slip-free fabric support
- Memory capacity approximately 10MB
- Reads embroidery designs with a stitch capacity of up to 750,000 stitches per design and 127 color changes
- Color Visualizer with favorite color selections
-
WXGA IPS TFT Color LCD Touch Screen shows
- Design placement using drag/drop and slide/scroll/pinch capacitive capabilities
- Enhanced Realistic Preview
- Screen brightness with 6 settings
- Design previews can be enlarged 400%
- Needle positioning grid and hoop selections
- Needle position image can be enlarged 200%
- Estimated embroidery time display and stitch count
- Embroidery progress bar
- Stitch simulator
- Needle advancement (1, 10, 100, or 1000 stitch increments)
- Measurements displayed in inches or metrics
- Color separation
- Thread color indicator
- On-screen hoop size indicator
- Low bobbin thread indicator with option to sew reinforcing stitches in embroidery mode
- 300 color names
- Screen saver customization
- Thumbnail images in 3 viewing sizes, defaults at 150%
- 9-Point trial check points
- Starting point key for instant alignment of characters or patterns
- Alternate bobbin case for pre-wound bobbins
- Customize embroidery pattern and thumbnail background colors (66 options)
- On-screen grid
- Cuts jump stitches (with on/off capability)
- Embroidery frame clearance setting for easy bobbin changes
- Embroider without removing the foot control
- Compatible with optional W+ Needle Beam Foot and mouse
Embroidery Editing Capabilities
- Combine embroidery designs on screen
- Character/text array function
- Character spacing
- Multi-line text with justification options
- Character insert and group edit capabilities
- Change fonts on letters or words after the design is set
- 0.1°, 1°, 10°, and 90° pattern rotation
- Enhanced design enlargement (up to 200%) and reduction (down to 60%) capabilities
- Design duplication
- Multiple design selection capabilities
- Automatic appliqué
- Automatic basting
-
Add automatic stippling, echo stitching, and decorative fill
patterns around embroidery designs
- Set the distance, spacing and frame size
- Mirror imaging
- Change color selections within designs
- Enhanced color sorting to optimize sewing order
- Monochrome option for embroidery designs
- Programmable custom thread color selection
- 14 Major thread brands color palettes built-in
Advanced Sewing Capabilities
- 864 Built-in stitches including
- 154 Utility including 15 one-step buttonhole styles and 1 four-step custom buttonhole
- 527 Decorative
- 79 Decorative satin
- 20 Satin
- 21 Cross
- 63 Combinable Utility stitches
- 3 Hand-look Quilting
- 4 Built-in alphabets
- 30 Quilting stitches offer 57 needle position options
- Stitch length 0.0mm - 5.0mm
- 2 Basting stitch options: Regular 5mm and free-motion
- Maximum Utility stitch width 7mm
- Utility stitch editing capabilities
- 5 Memory settings for each Utility stitch
- Decorative stitch editing capabilities
- Edit and combine Character Decorative stitches
- Character/Decorative stitch memory equaling 1MB
- Satin stitch elongation
- Mirror-image
- Back to the beginning key
- Single and repeat mode
- Length width proportional linking key
- Sew Utility and Decorative stitches while embroidery arm is attached
- Specify end-point for stitch line with capability to end with a completed pattern
- Automatic drop feed on screen
- Lock key for Utility and Decorative stitches
- Reinforcement priority settings
- Lateral and diagonal feeding
- Variable needle positions
- Fully automatic built-in darning
- Twin needle settings
Convenient Sewing Features
- Larger sewing bed and workspace with 13.1" to the right of the needle
- Frosted surface finish on machine bed
- Convenient one-touch buttons for
- Start/Stop
- Reverse sewing
- Reinforcement key
- Needle up/down
- Thread cutter
- Automatic presser foot lift
- Automatic needle threading
- Sewing speed control doubles as width control
- Quick-Set, Top-Loading bobbin with sensor
- Quick-Set Independent bobbin winding system with
- 5 Adjustable speed settings
- 5 Variable bobbin filling settings
- One finger removable needle plate for easy access cleaning
- Ergonomic 3-position, adjustable knee lift with extra high presser foot lift - 10mm Automatic and 13mm Manual
- Programmable 3-step needle up/down
- Adjustable volume with 5 settings
- Automatic thread cutter (with on/off capability)
- Needle plate with scale in inches and centimeters and additional guideline markings
- Free arm
- Foldable king two-spool thread stand attaches magnetically to machine lid
- Two accessory storage compartments in sewing tray
- Enhanced Accessory Storage Box with 3 interchangeable trays
- Compatible with optional Multi-Function Foot Control
Instruction and Help Resources
- Built-in Instructions and Reference Manual
- Built-in Operational Guide with up to 40 help topics and
- 42 built-in videos
- Built-in Sewing Application Guide
- Built-in Help Messages
- Embroidery Stitch Count System – SCS
- Capability to save settings screen images
Warranty
- 25 years limited
- 10 years parts
- 5 years computer circuit
- 5 years electrical
- 1 year labor
