Specifications
Technology Features
- LCD Color Touch Screen
- Shows 260,000 colors
- Measures 7" diagonally
- Clock and Date
- Guide Beam and Needle Beam for precision alignment of stitches
- Class 1 Laser Product (IEC60825-1:2007)
- Sensor Pen allows you to set preferences:
- Set a guideline for sewing
- Select the needle position location
- Select custom zigzag widths
- Choose an ending point on the fabric for stitches to stop sewing
- See the needle position location for embroidery
- Select precise placement for embroidery designs
- Enhanced Stadium Lighting™ for brighter true color LED lighting of 10" around the needle
- 2 USB drives: 1(Type A) drive, 2.0 connects with a mouse, hub, flash drives and CD-ROM drives and 1 (Type B) USB direct connect to a PC
- Access designs stored in folders when using USB Type A
- NeverMiss™ Threading System
- Automatic thread cutter
- Quick-Set, Top-Loading bobbin with sensor
- Quick-Set Independent bobbin winding system with variable speed
- Digital Dual-Feed System ensures utmost fabric control when feeding layers or difficult fabric types
- Automatic sensors
- Thread tension control makes tension adjustments for accurate stitches
- Upper and lower thread sensors to alert when threads run out
- On-screen hoop sensor to recommend size of hoop
- Embroidery speed up to 1,050 spm
Sewing Features
- 573 Built-in stitches including
- 137 Utility with 14 one-step buttonhole styles
- 283 Decorative
- 20 Satin
- 61 Decorative satin
- 14 Cross
- 58 Combinable Utility
- 5 Built-in alphabets
- Maximum utility stitch width: 7mm
- Stitch length 0.0mm - 5.0mm
- Digital Dual-Feed System ensures all layers feed evenly
- Automatic Fabric Sensor System adjusts presser foot pressure and tension to deliver perfect stitch
- Advanced Pivoting Feature
- Ergonomic hands-free presser foot lift with extra high setting 10mm automatic and 13mm manual
- 11.25" Workspace to the right of the needle
- LED lights illuminate 10" around the needle
- Sewing speed up to 1,050
- Automatic drop feed
Advanced Sewing Features
- Utility stitch editing capabilities
- Stores personal stitch settings for each Utility stitch on machine
- Decorative stitch editing capabilities
- Back to the Beginning key, returns to the beginning of a decorative stitch pattern
- Edit and combine Character/ Decorative stitches
- 24 Memory Pockets for Character/Decorative stitches equaling 1 MG
- Store additional stitch combinations on your PC using the 2 USB ports
- Mirror-image capability for stitches
- Lock key for stitches keeps current settings
- 57 Variable needle positions
- Programmable needle up/down
- Upper and lower thread sensors to alert when threads are broken
- Lateral and diagonal feeding
- Fully automatic built-in darning
- Twin needle settings
Embroidery Features
- Built-in embroidery design library
- • 266 Embroidery designs built-in
- 166 Baby Lock exclusive designs
- 12 Floral vine alphabet accents and frame patterns
- 13 Bobbin work designs
- 140 Frame combinations
- 19 Font styles including
- Exclusive script alphabet characters
- Large floral vine alphabet
- Embroiders up to 7" x 12" (180mm x 300mm) embroidery field
- Memory capacity 2MB
- Reads embroidery designs with a stitch capacity of up to 500,000 stitches per design
- Color Touch Screen shows:
- Design placement using drag and drop capabilities
- Estimated embroidery time display and stitch count
- Needle advancement (1, 10, 100 or 500 stitch increments)
- Measurements displayed in inches or metrics
- Color separation
- Thread color indicator
- On-screen hoop size indicator
- Low bobbin thread indicator
- 300 color names
- Embroidery speed up to 1,050 spm
- 9-point trial check points
- Starting point key for instant alignment of characters or patterns
- Alternate bobbin case for pre-wound bobbins
- Customize embroidery pattern and thumbnail background colors (66 options)
- Resume feature
- On-screen grid
- Cuts jump stitches (with on/off capability)
- Stitch Count System - .SCS
Embroidery Editing Features
- Combine embroidery designs on screen
- Character/text array function
- Character spacing
- 1°, 10°, and 90° Pattern rotation
- Design enlargement (up to 20%)
- Design reduction (up to 10%)
- Automatic appliqué
- Automatic basting
- Mirror imaging
- Change color selections within designs
- Color sorting on border designs
- Monochrome option for embroidery designs
- Programmable custom thread color selection
Convenience Features
- Convenient one-touch buttons for
- Start/Stop
- Reverse sewing
- Reinforcement stitch
- Needle up/down
- Thread cutter
- Automatic presser foot lift
- Auto threading
- Needle plate with scale in inches and centimeters
- Additional seam markings on bobbin cover for needle position preference
- Free arm
- Two accessory storage compartments
