Specifications
Technology Features
- Color LCD Touchscreen (4.85" X 2.5")
- Advanced Needle Threading System
- Automatic thread cutter
- Quick-Set, top loading bobbin
- Automatic Thread Tension Control
- Automatic Fabric Sensor System
- Advanced Pivoting Feature
- Quick-set bobbin winder
- Automatic sensors
- Thread tension control makes adjustments to feed thread properly
- Upper and lower thread sensors to alert when threads are broken
- On-screen hoop sensor to recommend size of hoop to use
Convenient Sewing Features
- Convenient One-Touch Buttons for
- Start/stop
- Reverse sewing
- Needle up/down
- Reinforcement Key
- Thread cutter
- Automatic presser foot lift
- Ergonomic hands-free presser foot lift
- Low bobbin thread indicator
- Needle plate with scale in inches and centimeters
- Electronic foot control
- Free arm with drop feed lever
- Hard cover case with storage
- Two accessory storage compartments
- Programmable needle up/down
- Quick-Set Bobbin Winder
Advanced Sewing Features
- 301 Built-in stitches including
- 100 Utility with 10 one-step buttonhole styles
- 94 Decorative
- 17 Satin
- 18 Decorative satin
- 14 Cross
- 58 Combinable Utility stitches
- 5 Built-in alphabets
- Maximum utility stitch width: 7mm
- Stitch length 0.0mm - 5.0mm
- Store personal stitch settings for each Utility stitch on machine
- Reset Key
- Decorative stitch editing capabilities
- Back to the Beginning key, returns to the beginning of a decorative stitch pattern
- Edit and combine Character/ Decorative stitches
- 15 Memory Pockets for Character/ Decorative stitches
- Step Stitch Pattern
- Mirror-image capability for stitches
- Variable needle positions
- Programmable needle up/down
- Lateral and diagonal feeding
- Automatic Fabric Sensor System adjusts presser foot pressure and tension to deliver perfect stitch
- Fully automatic built-in darning
- Twin needle settings
- 8.3" workspace to the right of the needle
- 2 LED enhanced lights that illuminate the needle & work area
- Sewing speed up to 850spm
- Drop feed
Embroidery Capabilities
- Embroidery design library built in
- 181 Built-in embroidery designs including 90 Baby Lock exclusive designs
- 140 Frame combinations
- 13 font styles including one exclusive script
- Embroiders up to 6-1/4" x 10-1/4" (160mm x 260mm) embroidery field
- 1MB Memory Storage for Embroidery
- Reads embroidery designs with a stitch capacity of up to 200,000 stitches per design
- Color LCD Touch Screen shows
- Estimated embroidery time display and stitch count
- Needle position placement (1, 10, or 100 stitch increments)
- Measurements displayed in inches or millimeters (mm)
- Thread color indicator
- On-screen hoop size indicator
- Low bobbin thread indicator
- 300 color names
Embroidery Editing Capabilities
- Combine embroidery designs on screen
- Font editing
- Size and select letters individual
- Ability to split text
- Multi-color text
- Multiple fonts
- Multi-line text
- Character/text array function
- Character spacing
- Horizontal and vertical options on Japanese fonts
- 1°, 10°, and 90° Pattern rotation
- Design enlargement and reduction (up to 20% down to 10%)
- Mirror imaging
- Design color selections
