Specifications
- 163 Stitches across 4 modes
- 7 one-step, sensor buttonholes
- Block and script monogram stitches
- AcuFeed: Built-in layered fabric feeding system
- Enhanced backlit LCD screen with more stitch details
- Start/stop button
- Favorite stitch settings default
- Maximum sewing speed: 1000spm/Straight; 700spm/Zigzag
- Automatic thread cutter, with memory capability
- Speed control lever
- Arm and bed space: 9" x 5" (225mm x 120mm)
- Visible pressure gauge
- Jam-proof, magnetic, top-loading, full-rotary hook system
- Independent motor for bobbin winding
- External feed balancing dial
- 7-point feed dog
- Front access feed dog up/down control
- Adjustable stitch width from 0 to 7mm
- Adjustable stitch length from 0 to 5mm
- Individual stitch editing
- Combination stitch editing
- Elongation
- Turn over memory
- Recall memory bank (5 memory banks)
- Resumption set/last stitch recall
- Auto-lock, Lock-a-matic, and needle up/down quick command keys
- Vertical thread delivery system with dual thread guide bar
- Built-in needle threader
- 71 needle drop positions (including 15 left to right needle positions)
- Extra-high presser foot lift
- Twin needle guard
- Knee lifter
- Extended seam allowance guide
- Beep indicator shut-off
- 14 standard feet
- Large extension table
- 10 languages available on-screen
- Electronic foot control
- Sewing light
- Soft dust cover
- Weight: 26.5lbs. (12 kg)
Warranty
Janome America, Inc. Limited 25 Year Warranty
Dear Customer,
We thank you for purchasing this Janome sewing machine (the "Product") and hope you will enjoy it for years to come. In the event that your Product needs service covered by this warranty, please contact the authorized Janome dealer from whom you purchased it or a Janome Authorized Service Center. To locate a Janome Authorized Service Center, please call 1-800-631-0183 or visit our web site at www.janome.com. Your product was sold with an instruction booklet and or a DVD/CD-ROM. To avoid any unnecessary inconvenience, we suggest that you refer to the instruction booklet before contacting your authorized Janome dealer or Janome Authorized Service Center for service. We also strongly encourage you to register your product on-line at www.janome.com.
Janome America, Inc. warrants that the Product will meet the written specifications of Janome all of which are within normal industry standards and included in the instruction booklet. This Janome warranty is exclusive to the original purchaser of the Product and is provided for normal household or commercial use. Janome America, Inc. warrants this Product for a period of twenty-five (25) years from the date of original purchase against defective materials and/or workmanship, excluding (I) electronic component parts (including but not limited to circuit boards, step motors and all other electronic and non-electronic pattern control units), which are warranted for a period of five (5) years from the date of purchase, and (II) labor, which shall be provided for a period of one (1) year from the date of purchase free of charge. Following a lapse of one (1) year from the original purchase date your Authorized Janome Dealer or Janome Authorized Service Center can provide parts and/or labor at an additional cost to you. As stated above, this warranty is in respect of normal household use of the Product. Machines used commercially are warranted for a period of one (1) year from the date of purchase in respect of parts and service. No further warranty shall apply to Products used for commercial purposes.
Each of the period described in paragraph 2 above shall hereafter be referred to as the "Warranty Period", together the "Warranty Periods".
Irrespective of whether the Product is used commercially or for normal household use, in no event shall this warranty cover needles, needle plates, bobbin cases, fuses, light bulbs, knives, loopers or belts.
This warranty is void - that is, the Product was purchased without warranty - if you did not purchase it from an authorized Janome dealer within the United States. A list of authorized Janome dealers within the United States is available by zip code on our website www.janome.com. This warranty will be honored only when the original invoice or sales receipt indicating the date of purchase, the product type and authorized Janome dealer's name is presented together with the defective product. This warranty will not apply if the serial number on the Product has been altered, deleted, removed or is illegible. This warranty covers non of the following, (I) periodic maintenance and repair or replacement of parts due to normal wear and tear, (II) postage, shipping and handling costs and all risks to the Product associated with shipment or transport, (III) damage resulting from misuse of the Product or failure to provide normal maintenance, (IV) repairs to the Product done by unauthorized dealers, service providers or the purchaser, (V) damage resulting from the use of non-Janome brand parts, supplies, or accessories; (VI) accidents, lightning, fires, water, power surges or any other cause beyond the reasonable control of Janome America, Inc.
If you suspect a defect in materials or workmanship of your Product, you must report it to the authorized Janome dealer from whom you purchased it or a Janome Authorized Service Center during the Warranty Period described in paragraph 2 above. Your authorized Janome dealer or Janome Authorized Service Center may require you to return the Product to it (properly packaged, freight prepaid) together with a photocopy of your original invoice or sales receipt.
Your authorized Janome dealer or Janome Authorized Service Center will evaluate your report of a possible defect and if one is discovered, will (at its option) repair or replace the Product either with an identical Product or with a substitute product that is substantially similar to the original Product. Your authorized Janome dealer or Janome Authorized Service Center reserves the right to supply refurbished Products or substitute product provided that they conform to the written specifications of Janome America, Inc. for new Products or new substitute products.
This warranty will also apply to any replacement Product or substitute product. For purposes of establishing the Warranty Period described in paragraph 2 hereof with respect to any replacement Product or substitute product, the original date of purchase of the original Product will continue to apply.
This warranty will be governed by the laws of the state in which you purchased the Product ("Applicable Law"). Unless otherwise required by Applicable Law, Janome shall in no event be liable for incidental or consequential damages arising directly or indirectly from the use or inability to use the Product or any substitute product for any reason. Any implied warranties of merchantability or fitness for purpose of the Product or any substitute product are limited to the Warranty Period described in paragraph 2 above. Other than as specified herein or as required by Applicable Law, all other warranties, conditions or liabilities, whether express or implied by operation of law or otherwise, are hereby expressly excluded, and Janome America, Inc. hereby disclaims all other warranties, conditions or liabilities.
